P-22 22m Trailer Fold Arm Boom Lift

22m｜200kg｜Portable｜Adaptable｜Cost-effective

The trailer boom lift is a versatile high-altitude work equipment, widely used in construction, maintenance, and cleaning tasks. It offers a working height range from 10 meters to 22 meters, providing various operational options. Users can choose between electric, diesel, or hybrid models to meet different environmental and operational requirements.

The trailer design makes it easy to tow and transport, suitable for both urban and rugged terrains, offering a convenient and safe platform for high-altitude work.

Модели и характеристики

P-22 22m Trailer Fold Arm Boom Lift

Модели и характеристики

Basic Pпродукт Pараметры
Высота подъема	22m
Maximum working radius	10m
Rotation angle	360 ° rotation
Размер платформы	1.20.71.1m（Customized wind resistant steel plate mesh with enlarged design）
Overall dimensions	5.7 * 1.5 * 2.3m
Rated load capacity	200 кг
Lifting method	Hydraulic lifting
Скорость подъема	0.05-0.09
Support method	Hydraulic leg support
Wind resistance level	Less than level 5
Device Color	Based on customer needs
Power display screen	Power display screen and display light
A Platform length	700 мм
B Platform width	1400mm
C Height – stowed	2150mm
D Length- stowed	8400mm
E Width- stowed	1480mm
G Length-outrigger footprint	4700mm
H Width-outrigger footprint	1200mm

Номер модели	P-10	P-12	P-14	P-16	P-18	P-20
Lifting Height (m)	10	12	14	16	18	20
Max Working Radius (m)	5.8	7.5	7.5	10.5	11	11
[A] Platform Length (m)	0.9
[B] Platform Width (m)	0.7
[C] Height – Stowed (m)	2.1			2.2	2.25	2.25
[D] Length – Stowed (m)	5.2	4.7	5.5	5.7	6	6.6
[E] Width – Stowed (m)	1.7	2.2	2.2	2.25	2.2	2.25
Rotation Angle	359°	360°
Размер платформы (м)	0.90.71.1	–	–	–	–	–
Overall Dimensions (After Folding) (m)	5.21.72.1	4.71.72.2	5.551.72.2	5.71.72.25	61.72.2	6.61.82.25
Rated Load Capacity (kg)	300	200
Общий вес (кг)	1950	1900	1900	2500	3300	4200
Lifting Method	Hydraulic lifting
Support Method	Hydraulic leg support
Device Color	Based on customer needs
