Plate-forme rotative d'essai et d'étalonnage de véhicules autonomes

POSTED: 1/10/2024

Project Overview

The client is a leading smart logistics and supply chain solutions company in China.

This system utilizes a servo motor for high-precision rotation, primarily applied in two phases of unmanned vehicle manufacturing: first, during the post-production testing phase, and second, in the design phase for calibrating the first prototype vehicle.

Vidéo d'utilisation

Paramètres de base

Spécifications	Détails
Modèle	BXZ5.0-5.0
Rotating Platform Diameter	5000 mm
Required Space Diameter	5100 mm
Platform Flatness	≤ ±4 mm
Platform Roundness	≤ ±3 mm
Maximum Speed	1 r/min
Minimum Speed	0.167 r/min
Hauteur de l'équipement	700 mm
Méthode d'installation	Indoor, 700 mm pit installation, flush with ground
Step Angle	10° (Error ≤ ±0.5°)
Charge nominale	5000 kg
Poids de l'équipement	4100 kg
Full Load Ground Load	464 kg/m²
Working Environment	Indoor
Température de fonctionnement	De -20°C à 60°C
Working Voltage	380V/AC/50Hz
Operation Panel	10-inch local touchscreen
Control Cabinet Buttons	Illuminated buttons
Panneau de contrôle	PLC
Motor Brand	Siemens
Motor Type	Stepper Motor (Pulse Motor)
Surface Treatment	Painted or powder-coated
Rotation Direction	±360°
Operating Mode	Step 10° every 10 seconds (adjustable)
Rotation Direction Setting	±
Rotation Speed Setting	1 to 6 minutes per rotation
Rotation Angle Setting	Integer multiples of 10°
Response Speed	≤ 0.5 s
Arbitrary Start/Stop	Oui
One-Key Reset	Automatic reset with one button
Smooth Start/Stop	Program-controlled smooth start and stop
Arrêt d'urgence	Controlled by emergency button
Protection contre les surcharges	Controlled by overcurrent relay
